Metravi AVM-02 Airflow & Temperature Meter with CFM CMM

Send Inquiry

Request To Call Back

Metravi AVM-02 Airflow & Temperature Meter with CFM CMM

Price 4189.00 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Metravi AVM-02 Airflow & Temperature Meter with CFM CMM Specification

Power Supply
9V battery

Application
HVAC, environmental monitoring, airflow and temperature measurement

Display Type
Large LCD display with backlight

Equipment Type
Airflow & Temperature Meter

Accuracy
Air Velocity: 3%+0.20, Temperature: 1C

Features
Data hold, Max/Min/Avg, Backlight, CFM/CMM Calculation, Low battery indicator

Mounting Type
Handheld

Temperature
0C to 50C

Resolution
Air Velocity: 0.01 m/s, Temperature: 0.1C

Response Time
1 second

Operating Voltage
9V battery operation

Measuring Range
Air Velocity: 0.4 to 30 m/s, Temperature: 0 to 50C, Airflow: 099,999 CFM/CMM

Test Range
Air Velocity: 0.430 m/s, Temperature: 050C

Humidity
Max 80% RH (non-condensing)

Automation Grade
Manual

Port Size
Standard vane (72mm diameter)

Usage
Measuring air velocity, airflow, and temperature

Machine Weight
200g (including battery)

Test Speed
0.4 to 30 m/s (air velocity range)

Control Mode
Manual

Data Functions
Hold, MIN, MAX, AVG

Auto Power Off
Yes (after 20 minutes idle)

Sampling Rate
1 time per second

Operating Temperature
0 to 50°C

Units of Measurement
m/s, ft/min, km/h, MPH, knots, °C, °F, CFM, CMM

Storage Humidity
<90% RH (non-condensing)

Low Battery Indication
Yes

Product Dimensions
156×67×28mm

Storage Temperature
-20 to 60°C

Protection Level
IP40

Sensor Type
Vane anemometer

Metravi AVM-02 Airflow & Temperature Meter with CFM CMM Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID), Cheque, Cash Advance (CA)

About Metravi AVM-02 Airflow & Temperature Meter with CFM CMM

Hand Held Pocket type Anemometer
Measures Air Speed, Air Flow (CMM/CFM/CMS)
Low Battery and Over range indication
Data Hold, Max / Min record function
4 Digits Backlit LCD Display with analogue bargraph
Range of Wind Speed: 0.8 to 40m/s with an accuracy of 2%
0.8 to 77.70 knots with an accuracy of 2%
1.4 to 144.0 km/hr with an accuracy of 2%
1.3 131.20 ft/s with an accuracy of 2%
0.90 90.00 mil/h with an accuracy of 2%
78 7874 ft/min with an accuracy of 2%
Range of Air Flow: 0 99990 CFM / CMM / 9999 CMS

Precise Airflow & Temperature Measurements

The AVM-02 delivers reliable readings for air velocity (0.4-30 m/s) and temperature (0-50C), suitable for professionals in HVAC and environmental assessment. With a vane sensor and high accuracy, users can confidently monitor airflow conditions in various settings.

User-Focused Features

Equipped with a large LCD display, data hold, backlight, and calculation capabilities for CFM/CMM, the AVM-02 enhances productivity and simplifies data interpretation. Manual control and quick response ensure precise operation and user convenience.

Portable and Durable Design

At just 200g and with compact dimensions, the AVM-02 is engineered for handheld use. IP40 protection and easy battery replacement promote long-term reliability, making it suitable for work sites, laboratories, and field inspections.

FAQ's of Metravi AVM-02 Airflow & Temperature Meter with CFM CMM:

Q: How do I use the Metravi AVM-02 Airflow & Temperature Meter for measuring airflow and temperature?

A: You simply hold the device in the direction of airflow and select your desired unit of measurement. The vane sensor instantly detects air velocity and temperature, and the large LCD display shows real-time results. Data hold and backlight functions facilitate easy reading in various environments.

Q: What applications is this meter suitable for, and where can it be used?

A: The AVM-02 is ideal for HVAC system analysis, environmental monitoring, industrial airflow checks, and laboratory tasks. Its portability and durable build make it suitable for work sites, indoor spaces, or field inspections in India and beyond.

Q: When should I expect the device to automatically power off?

A: The AVM-02 features auto power off after 20 minutes of inactivity, helping to conserve battery life during periods when the device is not in use.

Q: What is the measurement accuracy and range of this meter?

A: The meter measures air velocity in the range of 0.4 to 30 m/s with an accuracy of 3%+0.20 and a resolution of 0.01 m/s. Temperature measurement ranges from 0 to 50C with a resolution of 0.1C and accuracy 1C.

Q: How can I benefit from the data functions such as Hold, MIN, MAX, and AVG?

A: These functions allow users to record and review specific readings: Hold freezes the display for recording, MIN and MAX reveal the lowest and highest measured values, while AVG provides the average reading throughout a measurement session for comprehensive analysis.

Q: What is the process for replacing the battery, and what power source does it use?

A: The AVM-02 operates on a standard 9V battery. To replace, simply open the battery compartment, remove the old battery, and insert a new one. The low battery indicator on the display will alert you when replacement is needed.

Q: Is the meter effective in environments with humidity, and what is its operating condition range?

A: Yes, the meter operates efficiently in environments with humidity up to 80% RH (non-condensing) and temperatures between 0 to 50C. The storage humidity can reach 90% RH, ensuring reliability in diverse operating conditions.
