Metravi CE-0102D Phase Angle Meter

Price 3717.00 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Metravi CE-0102D Phase Angle Meter Specification

Response Time
2 seconds

Accuracy
2

Mounting Type
Handheld

Measuring Range
0360

Application
Measurement of phase angle between two voltages or currents in electrical systems

Humidity
85% RH

Frequency
45Hz 65Hz

Temperature
0C to 40C

Interface Type
Test leads connection

Display Type
3-1/2 digit LCD display

Automation Grade
Manual

Equipment Type
Digital Phase Angle Meter

Operating Voltage
220V/380V AC (test voltage)

Power Supply
1 x 9V Battery (6F22)

Features
Portable, battery-operated, easy to use, backlit display, robust construction

Resolution
1

Usage
Phase angle measurement in electrical installation, commissioning, troubleshooting, and maintenance

Machine Weight
Approx. 190g (including battery)

Control Mode
Manual

Input Signal Voltage Range
100V, 220V, 380V AC (50/60Hz)

Colour
Yellow and Black

Sampling Rate
3 times/second

Dimension
155mm x 77mm x 36mm

Storage Temperature
-10C to 60C

Over Range Indication
Display shows 1

Safety Standard
IEC61010-1 Cat. III 600V

Input Impedance
Approx. 1M

Low Battery Indication
Provided

Metravi CE-0102D Phase Angle Meter Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cheque, Cash in Advance (CID), Cash Advance (CA)

Supply Ability
10 Pieces Per Day

About Metravi CE-0102D Phase Angle Meter

Micro-Controller Based
Size Available 96 x 96 or 96 x 48 mm sq
Display 3-1/2 Digits Red LED Display
Range -180.0 to + 180.0
Input 300V AC & 5A AC
Voltage to Voltage & Voltage to Current options available
Auxiliary Power Supply 230 / 110V AC 50Hz (Any One)

Accurate Phase Angle Measurement

The Metravi CE-0102D precisely measures phase angles from 0 to 360, supporting electrical professionals during installation, commissioning, and diagnostics. Its consistent 2 accuracy and rapid 2 second response time ensure dependable results, making it a valuable tool for both routine and complex tasks.

User-Friendly and Robust Design

Designed for portability, the CE-0102D weighs only about 190g (with battery) and features a rugged build, able to withstand challenging on-site conditions. The backlit, clear LCD enables use even in dim environments, while manual controls and straightforward test lead connections promote intuitive operation.

FAQ's of Metravi CE-0102D Phase Angle Meter:

Q: How do I use the Metravi CE-0102D Phase Angle Meter for measurements?

A: Simply connect the provided test leads to the two points whose phase angle you wish to measure, select the appropriate voltage and frequency range, and read the measured angle directly from the large LCD display. Ensure the device is securely connected and operates within prescribed voltage limits for accurate results.

Q: What electrical applications is the CE-0102D suited for?

A: This meter is ideal for measuring phase angles in electrical installations, commissioning, troubleshooting, and general maintenance. It's widely used by electricians, engineers, and technicians working with AC power distribution systems operating at 100V, 220V, or 380V.

Q: When will the over range indication be triggered on this meter?

A: The display will show '1' whenever the input signal exceeds the acceptable measurement range or the device senses a value beyond its specified capability, indicating the reading cannot be displayed properly and the measurement should be checked.

Q: Where should the CE-0102D be stored when not in use?

A: Store the meter in a dry environment within a temperature range of -10C to 60C and relative humidity less than or equal to 85% RH. Proper storage ensures the device remains accurate and extends its service life.

Q: What is the process for replacing the battery in the CE-0102D?

A: Replace the 9V (6F22) battery by opening the battery compartment on the rear of the unit. Always turn the device off before changing the battery, and ensure the new battery is installed according to the indicated polarity to prevent damage.

Q: How does the CE-0102D benefit electrical professionals during troubleshooting?

A: Its fast sampling rate, wide input range, and clear indications (including low battery and over range) facilitate quick, reliable troubleshooting. The portable, backlit design enables measurements in remote or dimly-lit conditions, improving job efficiency and safety.
