Metravi PRO Solar-1 PV Digital Multimeter with Bluetooth Connectivity

Send Inquiry

Request To Call Back

Metravi PRO Solar-1 PV Digital Multimeter with Bluetooth Connectivity

Price 17877.00 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Metravi PRO Solar-1 PV Digital Multimeter with Bluetooth Connectivity Specification

Mounting Type
Handheld

Features
True RMS, Bluetooth, Auto-Ranging, NCV

Port Size
Standard Banana Jack

Equipment Type
Solar PV Digital Multimeter

Automation Grade
Semi-Automatic

Resolution
0.001V

Interface Type
Bluetooth Connectivity

Display Type
Large Digital LCD with Backlight

Operating Voltage
9V

Power Supply
9V Battery or USB Charging

Test Range
DCV up to 1500V, ACV up to 1000V

Humidity
0-80% RH (non-condensing)

Response Time
Instantaneous (within 2 seconds)

Temperature
0C to 40C

Application
Solar PV System Testing, Electric Measurements

Measuring Range
DC Voltage: 0~1500V; AC Voltage: 0~1000V; Current: 0~10A

Accuracy
(0.5% + 5 digits)

Frequency
45~65Hz

Usage
Field & Laboratory

Machine Weight
Approx. 500g

Control Mode
Manual/Button

Continuity Test
Audible buzzer <30

Bluetooth Range
Up to 10 meters

Safety Rating
CAT III 1000V, CAT II 1500V

Low Battery Indication
Yes

Peak Hold
Yes

Auto Power Off
Yes, with disable option

Input Impedance
>10M (V measurements)

Relative Mode
Yes

Diode Test
Yes, up to 3V

Capacitance Range
1nF to 9999F

Data Hold
Yes

Dimensions
Approx. 210mm x 95mm x 55mm

Batteries Required
2 x 1.5V AA

Overload Protection
Yes, with physical fuses

App Compatibility
Android & iOS supported App

Temperature Measurement
-20C to 1000C (with K-type probe)

Metravi PRO Solar-1 PV Digital Multimeter with Bluetooth Connectivity Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cheque, Cash in Advance (CID), Cash Advance (CA)

Supply Ability
10 Pieces Per Week

About Metravi PRO Solar-1 PV Digital Multimeter with Bluetooth Connectivity

Display : 6000 Counts.
Bluetooth : 4.0
Data Logging : 4000 Data Memory
Over Range Indication
Measure : Samples 3 times per second.
Non Contact Voltage detection
MIN/MAX/REL
Data Hold
Auto Power Off
T-RMS
CAT III 1000V
CAT IV 600V
EN 61326-1
DCmV: 0600.0mV
Accuracy: (0.5%+5D)
DC Voltage: 06.000V/60.00V/600.0V/1000V
Accuracy: (0.5%+2D)
AC Voltage (TRMS): 06.000V/60.00V/600.0V/1000V
Accuracy: (1.0% + 3D)
PV DC Voltage: 0600.0V/2000V
Accuracy: (2.0%+5D)
PV AC Voltage: 0600.0V/1500V
Accuracy: (2.0%+5D)
DC Current: 06.000A/10.00A
Accuracy: (1.0%+3D)
AC Current (TRMS): 06.000A/10.00A
Accuracy: (1.5%+3D)
Resistance: 0600.0?/6.000k?/60.00k?/600.0k?/6.000M?/40.00M?
Accuracy: (0.9%+2D)
Capacitance: 01.000uF/10.00uF/100.0uF/1.000mF/10.00mF
Accuracy: (1.9%+2D)
Frequency: 0100.00Hz/1000.0Hz/10.000kHz/100.00kHz
VoltSeek( NCV): High Sensitivity: 80V -1000V, Low Sensitivity: 160V-1000V
Temperature: 40.0C to 400.0C
Accuracy: (1%+20D)
Diode and Continuity

Advanced Measurement Capability

Metravi PRO Solar-1 offers a wide voltage test range DCV up to 1500V and ACV up to 1000V with high accuracy and instant response. Designed for solar PV systems, it also supports current measurement up to 10A, capacitance, diode testing, continuity with audible alerts, and temperature readings from -20C to 1000C.

Reliable Connectivity and App Support

Integrate seamless monitoring with Bluetooth connectivity, enabling real-time data transfer up to 10 meters via iOS and Android apps. Easily access, store, and share your measurements remotely for effective field and laboratory diagnostics.

Safety and Durability

This multimeter is equipped with a robust safety rating (CAT III 1000V, CAT II 1500V), overload protection with physical fuses, and a tough ergonomic design. Additional features such as auto power-off, low battery indication, and standard banana jacks enhance dependable performance and user protection.

FAQs of Metravi PRO Solar-1 PV Digital Multimeter with Bluetooth Connectivity:

Q: How does the Bluetooth connectivity work on the Metravi PRO Solar-1 multimeter?

A: The Bluetooth feature allows data transmission up to 10 meters to your smartphone. Connect the device via the manufacturers app, available for Android and iOS, to monitor measurements in real time and access historical data remotely while working in the field.

Q: What types of electrical measurements can this multimeter perform?

A: The Metravi PRO Solar-1 measures DC voltage (0~1500V), AC voltage (0~1000V), current (0~10A), capacitance (1nF9999F), temperature (-20C to 1000C with probe), conducts diode tests (up to 3V), continuity tests with an audible buzzer, and also includes features like True RMS and NCV detection.

Q: When should I use the overload protection feature?

A: Overload protection is automatically activated whenever measured values exceed safe limits. This feature, combined with physical fuses, safeguards the device and the user during high-voltage or current measurements, especially in potentially hazardous solar PV or electrical environments.

Q: Where is this device most effectively utilized?

A: The Solar-1 is perfect for both field and laboratory settings, including diagnosing solar PV systems, regular electrical maintenance, and troubleshooting in industrial and utility installations due to its robust safety, portability, and accurate multi-functionality.

Q: What is the process to measure temperature with this multimeter?

A: Simply connect the accompanying K-type thermocouple probe to the multimeter, select the temperature measurement mode, and place the probe on the target surface. The device instantly displays temperature readings ranging from -20C to 1000C on its large LCD.

Q: How do the auto power-off and data hold features benefit users?

A: Auto power-off helps preserve battery life by shutting down the device after periods of inactivity, while the data hold function allows you to capture and retain important readings for later review or documentation, making fieldwork more efficient.

Q: What power options are available for this device?

A: The Metravi PRO Solar-1 can operate using 2 x 1.5V AA batteries, a 9V battery, or USB charging, providing flexible options to match varying usage scenarios and ensuring dependable operation wherever you are.
