Metravi RLD-01 Refrigerant Gas Leakage Detector

Price 11387.00 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Metravi RLD-01 Refrigerant Gas Leakage Detector Specification

Display Type
LED Visual Indicators + Audible Alarm

Features
Flexible probe, adjustable sensitivity, low battery indication, automatic zero adjustment

Temperature
0C to 52C (Operating Temperature)

Power Supply
3V DC (2 x 1.5V AA batteries)

Response Time
3 seconds

Application
Detection of various refrigerant gas leaks (air conditioning, refrigeration units, etc.)

Operating Voltage
3V DC

Humidity
Max 80% RH (non-condensing)

Mounting Type
Handheld

Automation Grade
Manual

Measuring Range
Detects refrigerant gas concentration as low as 4 grams/year

Usage
Portable gas detection

Machine Weight
approximately 420g (including batteries)

Control Mode
Manual

Sensitivity Adjustment
7 levels

Body Material
ABS Plastic

Battery Status Indicator
Available

Storage Temperature
-18°C to 52°C

Equipment Type
Refrigerant Gas Leakage Detector

Warm-up Time
Approx. 6 seconds

Detectable Gases
CFCs, HCFCs, HFCs (e.g., R-22, R-134a, R-410A, R-407C, R-1234yf, etc.)

Dimensions
220mm x 65mm x 45mm

Sensor Tip Length
Flexible 355mm (14 inches) probe

Alarm Type
Audible and LED visual indication

Metravi RLD-01 Refrigerant Gas Leakage Detector Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Cash in Advance (CID), Cheque

Supply Ability
100 Pieces Per Week

About Metravi RLD-01 Refrigerant Gas Leakage Detector

Detects all CFC refrigerants such as R-22, R-124, R-11 and R-12
The ultra-sensitive long life sensor detects the more current, difficult-to-detect HFC refrigerants such as R-134a, R-404A, and new R-22 replacements, R-410A and R-407C.
Its long, slim gooseneck probe design is easy to use in close areas and for extending into hard-to-reach areas.
Its adjustable alarm, easy one-hand operation and impact resistance storage case add up to value and convenience
Sensitivity to detect: 100ppm of R-134A/R-22
Response Time < 2 sec
Audio and Visual Alarm

Advanced Detection Capabilities

The Metravi RLD-01 is engineered to identify low concentrations of refrigerant gases, with a detection threshold as low as 4 grams per year. Its flexible probe accesses tight spaces, making it suitable for a range of applications including servicing air conditioning units and refrigeration systems. The device responds rapidly, alerting users within 3 seconds of leak detection.

User-Friendly Operation

Featuring seven levels of sensitivity adjustment and both visual and audible alarms, the RLD-01 allows users to customize settings for different environments. Its manual control mode and automatic zero adjustment simplify operation without compromising accuracy. The handheld design ensures convenient portability, while the ABS plastic body provides durability.

Reliable Performance in Varied Conditions

The RLD-01 operates effectively within 0C to 52C and up to 80% relative humidity (non-condensing), accommodating diverse climate requirements. The battery status indicator and 3V DC power supply (using two AA batteries) ensure uninterrupted usage during extended fieldwork. Its compact dimensions and lightweight construction add to usability for long inspection periods.

FAQ's of Metravi RLD-01 Refrigerant Gas Leakage Detector:

Q: How does the Metravi RLD-01 Refrigerant Gas Leakage Detector identify gas leaks?

A: The device uses a sensitive sensor and a flexible 355mm probe to detect refrigerant gases such as CFCs, HCFCs, and HFCs. When a leak is found, the detector provides both audible and LED visual alarms for instant notification.

Q: What refrigerant gases can the RLD-01 detect?

A: The RLD-01 is capable of detecting various refrigerant gases, including commonly used options like R-22, R-134a, R-410A, R-407C, R-1234yf, and similar CFCs, HCFCs, and HFCs.

Q: Where is the RLD-01 best used?

A: This detector is ideal for identifying leaks in air conditioning systems, refrigeration units, and HVAC installations. Its portable design makes it suitable for on-site and routine inspections by technicians.

Q: What is the sensitivity level adjustment and why is it useful?

A: The RLD-01 offers seven adjustable sensitivity levels, allowing users to fine-tune detection accuracy based on the environment and the suspected gas concentration, improving precision and reducing false alarms.

Q: How long does it take for the device to warm up and respond to leaks?

A: It requires approximately 6 seconds to warm up and can respond to detected leaks in about 3 seconds, enabling quick and efficient leak identification.

Q: How does the battery status indicator benefit users?

A: The battery status indicator ensures that users are aware of the device's power level, preventing unexpected shutdowns during inspections and ensuring consistent performance.

Q: Is the RLD-01 suitable for use in humid or extreme temperature conditions?

A: Yes, the RLD-01 functions reliably in conditions up to 80% relative humidity (non-condensing) and operates within a temperature range of 0C to 52C, making it appropriate for diverse environments.
