Metravi DIT-99A Digital Insulation Tester

Send Inquiry

Request To Call Back

Metravi DIT-99A Digital Insulation Tester

Price 2537.00 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Metravi DIT-99A Digital Insulation Tester Specification

Test Range
250V, 500V, 1000V (insulation test voltages)

Application
Testing insulation resistance of electrical equipment and wiring

Resolution
0.01M

Power Supply
1.5V AA size x 6 (Alkaline batteries)

Accuracy
(3%rdg+5dgt)

Response Time
Immediate/Instantaneous readings

Display Type
Large LCD Display

Features
Auto power off, data hold, low battery indication, backlight display

Temperature
0C to 40C (operating), -10C to 60C (storage)

Operating Voltage
250V, 500V, 1000V

Equipment Type
Digital Insulation Tester

Frequency
50Hz/60Hz

Measuring Range
0.01M to 999M

Automation Grade
Manual

Humidity
85% RH (relative humidity, no condensation)

Mounting Type
Handheld/Portable

Usage
Insulation resistance, AC/DC voltage measurement, continuity test

Capacity
Max output voltage 1000V

Machine Weight
Approx. 600g (including battery)

Control Mode
Manual

Dimensions
185mm x 140mm x 70mm

Safety Standards
IEC61010-1, CAT III 1000V

Short Circuit Current
1.8mA

Backlight Display
Yes

Data Hold Function
Yes

Test Voltage
250V / 500V / 1000V DC selectable

Auto Power Off
Yes, after 10 minutes of inactivity

Overload Protection
AC/DC 1000V for insulation and continuity ranges

Insulation Resistance Range
0.01M to 999M

DC Voltage Range
30V to 1000V DC

Continuity Test
Yes, with buzzer

Low Battery Indication
Yes

AC Voltage Range
30V to 750V AC

Metravi DIT-99A Digital Insulation Tester Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID), Cheque, Cash Advance (CA)

About Metravi DIT-99A Digital Insulation Tester

Battery Cum Mains Operated
Data Hold Function
Fault Protection, Buzzer Alarms if short circuit
Display: 3-1/2 Digits 1999 Counts LCD
Low Battery Indication
Test Voltage 100V
Insulation Resistance Range 200M.Ohms
Accuracy: 4%

Advanced Insulation Testing for Safety Assurance

The Metravi DIT-99A delivers reliable insulation resistance testing for a variety of electrical applications. Featuring selectable test voltages and high accuracy, it safeguards both devices and users with overload protection and adherence to international safety standards.

User-Friendly Operation and Features

Designed for ease of use, this insulation tester includes a backlit LCD, data hold function, auto power off after 10 minutes, and a handy buzzer for continuity tests. Its clearly marked controls and comfortable size allow efficient onsite measurements.

Versatile and Portable Design

Lightweight and handheld, the DIT-99A allows users to perform insulation and voltage measurements anywhere. With robust construction and multiple features, it is perfect for fieldwork, industrial settings, and routine maintenance checks.

FAQ's of Metravi DIT-99A Digital Insulation Tester:

Q: How do I select the appropriate test voltage on the Metravi DIT-99A?

A: You can manually choose between 250V, 500V, or 1000V test voltages using the selector switch on the device, depending on your application's insulation requirement.

Q: What benefits does the auto power off feature offer?

A: The auto power off function conserves battery life by automatically shutting off the tester after 10 minutes of inactivity, ensuring longer operation and reducing maintenance.

Q: Where can I use the Metravi DIT-99A insulation tester?

A: This tester is suitable for use in electrical maintenance, wiring inspections, industrial installations, and laboratory environments, wherever insulation resistance or voltage measurement is required.

Q: What is the process for conducting a continuity test using this device?

A: To perform a continuity test, connect the probes to the circuit under test and listen for the built-in buzzer, which sounds if continuity is present. The easy-to-read display provides immediate confirmation.

Q: When should the batteries be replaced?

A: Replace the AA batteries when the low battery indicator appears on the display to ensure reliable measurements. The tester uses six 1.5V AA-size alkaline batteries.

Q: How does the DIT-99A ensure user safety during operation?

A: With overload protection up to AC/DC 1000V and compliance with IEC61010-1, CAT III 1000V safety standards, the tester effectively prevents electrical hazards during insulation and voltage tests.

Q: What advantages does the data hold function provide?

A: The data hold function allows you to freeze and review a reading on the large LCD display, making it easier to record measurements, especially in areas with limited visibility.
